SoundPro X5 Professional Accordion MIDI & Sampling System

Accordion MIDI Sampler System — SoundPro X5

The accordion MIDI sampler system from SoundPro X5 combines complete right-hand, Bass and Chord MIDI control with an integrated SD-card sound engine. It reproduces layered sounds directly from the accordion and provides programmable control for live performance, rehearsal and studio work.

Complete MIDI control

• Up to 46 Main, 12 Bass and 12 Chord inputs — 70 configurable sensor inputs in total
• Individual assignment of every sensor to any MIDI note from 0 to 127
• Independent MIDI channels from 1 to 16 for Main, Bass and Chord
• 10 banks with 10 preset positions per bank, providing 100 registrations
• Editable preset names, MIDI Bank Select and Program Change
• Up to 16 configurable accordion-register combinations
• 16 configurable hardware User buttons

User buttons can control presets, banks, registers, transpose, octave, volume, Bass functions, bellows control, Pitch Bend, modulation, WAV playback and direct access to system pages.

Integrated professional sampler

• 48 kHz / 16-bit mono and stereo sample playback
• Up to 28 simultaneous voices, including up to 26 streamed voices
• Up to 254 sampler presets
• Four independent Upper sound layers
• Up to 1024 sample-map zones
• Direct stereo audio output
• Sounds and banks stored on SD card

Sound shaping and effects

SoundPro X5 provides per-layer volume, balance, transpose, octave and note-range control. The verified effects section includes a 10-band equalizer, reverb, chorus, delay, compressor and enhancer.

Touchscreen and bellows expression

The 480 × 320 color touchscreen provides fast access to presets, MIDI settings, sample layers, sensor mapping, effects, registers and system configuration. Brightness and screen-sleep timing are adjustable.

Bellows expression supports center, pull and push calibration, minimum and maximum sensor values, three predefined response profiles and one customizable profile.

Performance tools

• Scala / Terka learning: detection from three played notes with 12 selectable modes
• WAV player: up to 96 tracks with adjustable playback tempo from 70% to 130%
• Bass Learning: up to 10 songs, 256 melody notes and 512 accompaniment events per song, with tempo from 40 to 240 BPM
• Control for up to 13 RGB LEDs

SoundPro X5 Bank Manager

The included computer software supports creation and validation of compatible sound banks, importing mono or stereo WAV samples, mapping note and velocity zones, configuring loops and envelopes, managing presets and preparing the required files for the SD card.

Configuration memory

Preset names, MIDI channels, sensor-note assignments, register mappings, User-button functions, bellows calibration, display settings and sampler parameters are stored by the system. Backup, restore and factory-reset functions are available.

Installation notice: The sensor quantity, mechanical installation and wiring must be adapted to the accordion. The system requires correct 5V power, an SD card prepared with compatible SoundPro X5 bank files and suitable stereo amplification or headphones for audio monitoring.

Complete performance workflow

This accordion MIDI sampler system allows the musician to prepare registrations that coordinate melody, bass, chords, bellows response, effects and audio layers. After the sensors are installed and calibrated, presets can be selected from the touchscreen or the 16 User buttons. Stereo output can be connected to headphones, powered speakers, an amplifier or a mixer.

Installation and related equipment

Professional installation is recommended because sensor position, wiring, 5V power, MIDI configuration and audio routing must match the accordion. For wireless reception with compatible equipment, see the Fulgerton RX Ultra wireless MIDI receiver. General technical information about MIDI is available from the MIDI Association.

Using the accordion MIDI sampler system on stage

The accordion MIDI sampler system can store separate registrations for different songs, playing styles and ensembles. Test every layer, section and controller with the final amplification setup, then keep a verified backup of the working configuration and SD-card files.
